Kreyer MiniChilly chiller

Kreyer MiniChilly chiller

Enquire Online

The Kreyer range of refrigeration and heating units are manufactured by internationally renowned Kreyer, a WTG Quantor brand, who have over 40 years of specialist knowledge in wine temperature control at all stages of vinification. The units are designed to meet the rigorous requirements of modern winemaking. They are also ideal for the temperature control of beer, cider, juice, spirits and soft drinks (see Kreyer tab).

The MiniChilly is a compact cooling unit, made of stainless steel, and an ideal solution for nano scale scale drink producers who only need cooling for their applications.

  • Available in 3 sizes with cooling capacities of 0.5 to 1.7 kW (0.67 to 2.21 HP)
  • At 0°C (32°F) water temperature an ice-bank will be built around the tubes which provides an additional, stored cooling capacity
  • Able to cool water down to -6°C using glycol
  • When used for flash-cooling, it boosts the capacity of the unit, giving a constant cooling temperature over a longer time period
  • An additional stainless steel coil for direct cooling of liquids can be integrated as an option, even afterwards

Whether you require an individual unit or a complete cooling/temperature control system with ringmains and Speidel tanks* (insulated or standard) with heating/cooling jackets, we can help.

Our engineers install and commission complete cooling/temperature regulation systems, this includes the construction of a bespoke ringmain (pipework) and bracketry.

To read more about the 'whys' and 'hows' of temperature control, please see our blog Temperature Control.

See the 'Kreyer' tab below for customer Case Studies.

Please call us on 01404 892100 to discuss your temperature control requirements.



Please see the Temperature Control & Chilling category for our full range of Kreyer equipment.

(*) Please see the Tanks category in Catalogue for Speidel's stainless steel tanks.

For Glycol, please see Monoporpylene Glycol 1 litre - part code 94396

The Kreyer range of refrigeration and heating units are manufactured by internationally renowned Kreyer, a WTG Quantor brand, who have over 40 years of specialist knowledge in wine temperature control at all stages of vinification. The units are designed to meet the rigorous requirements of modern winemaking. They are also ideal for the temperature control of beer, cider, juice, spirits and soft drinks (see Kreyer tab).

The MiniChilly is a compact cooling unit, made of stainless steel, and an ideal solution for nano scale scale drink producers who only need cooling for their applications.

  • Available in 3 sizes with cooling capacities of 0.5 to 1.7 kW (0.67 to 2.21 HP)
  • At 0°C (32°F) water temperature an ice-bank will be built around the tubes which provides an additional, stored cooling capacity
  • Able to cool water down to -6°C using glycol
  • When used for flash-cooling, it boosts the capacity of the unit, giving a constant cooling temperature over a longer time period
  • An additional stainless steel coil for direct cooling of liquids can be integrated as an option, even afterwards

Whether you require an individual unit or a complete cooling/temperature control system with ringmains and Speidel tanks* (insulated or standard) with heating/cooling jackets, we can help.

Our engineers install and commission complete cooling/temperature regulation systems, this includes the construction of a bespoke ringmain (pipework) and bracketry.

To read more about the 'whys' and 'hows' of temperature control, please see our blog Temperature Control.

See the 'Kreyer' tab below for customer Case Studies.

Please call us on 01404 892100 to discuss your temperature control requirements.



Please see the Temperature Control & Chilling category for our full range of Kreyer equipment.

(*) Please see the Tanks category in Catalogue for Speidel's stainless steel tanks.

For Glycol, please see Monoporpylene Glycol 1 litre - part code 94396

View full details

The Kreyer range of refrigeration and heating units are manufactured by internationally renowned Kreyer, a WTG Quantor brand, who have over 40 years of specialist knowledge in wine temperature control at all stages of vinification. The units are designed to meet the rigorous requirements of modern winemaking. They are also ideal for the temperature control of beer, cider, juice, spirits and soft drinks (see Kreyer tab).

The MiniChilly is a compact cooling unit, made of stainless steel, and an ideal solution for nano scale scale drink producers who only need cooling for their applications.

  • Available in 3 sizes with cooling capacities of 0.5 to 1.7 kW (0.67 to 2.21 HP)
  • At 0°C (32°F) water temperature an ice-bank will be built around the tubes which provides an additional, stored cooling capacity
  • Able to cool water down to -6°C using glycol
  • When used for flash-cooling, it boosts the capacity of the unit, giving a constant cooling temperature over a longer time period
  • An additional stainless steel coil for direct cooling of liquids can be integrated as an option, even afterwards

Whether you require an individual unit or a complete cooling/temperature control system with ringmains and Speidel tanks* (insulated or standard) with heating/cooling jackets, we can help.

Our engineers install and commission complete cooling/temperature regulation systems, this includes the construction of a bespoke ringmain (pipework) and bracketry.

To read more about the 'whys' and 'hows' of temperature control, please see our blog Temperature Control.

See the 'Kreyer' tab below for customer Case Studies.

Please call us on 01404 892100 to discuss your temperature control requirements.



Please see the Temperature Control & Chilling category for our full range of Kreyer equipment.

(*) Please see the Tanks category in Catalogue for Speidel's stainless steel tanks.

For Glycol, please see Monoporpylene Glycol 1 litre - part code 94396

  • Cooling water temperature range from -6°C to +30°C (from 21.2°F to 86°F)
  • Ambient temperatures from from +10°C to +32°C (from 50ºF to 89.6°F)
  • Ice-bank at 0°C water temperature
  • Stainless steel coil for direct product cooling available as optional extra
  • Passive cooling of fermentation and storage
  • Cooling of must and wine for pre-clearing and crystal stabilisation
  • Cooling of rooms and storage halls - NB: with additional fan coils
  • With stainless steel coil (optional extra): direct cooling of liquids (active cooling)
  • Available in three models: MiniChilly 05 / MiniChilly 09 / MiniChilly 17
  • Cooling capacity: 0.5 - 1.7 kW (0.67 - 2.21 HP)
  • Refrigerant: R134a
  • Electric connection: 230V/1Ph/50/60Hz
  • Water inlet / outlet: 3/4" AG

WTG Quantor (incorporating Kreyer) manufacture technologically advanced cooling and temperature regulation systems for drink producers.

Their range includes equipment for refrigeration and temperature control at all stages of drink production, either at tank level, room level or through direct cooling or heating. We choose Quantor for the following reasons:

  • They have 40 years specialist experience supplying temperature control technology to wineries across the world - their range now incorporates other drink sectors, including beer, cider, spirits and fruit juices
  • Their cooling and temperature control systems have a well-earned, proven reputation in wineries throughout the world - they now export to more than 80 countries across the world in all 5 continents
  • They have developed innovative systems for temperature regulation, CO2 monitoring, micro/macro oxygenation, and room temperature control
  • They manufacture in-house

Company Development

The Kreyer brand was founded in 1970 in Villefranche sur Saône, France - the centre of the Beaujolais wine production area. In 1998 the company changed ownership and was incorporated by Wine Technology GmbH (WTG), an Austrian, American & German partnership, and since then headquarters have been located in the triangle of Germany, France & Luxembourg, in the heart of the Mosel winegrowing region. Further company expansion led to the development of larger production facilities. The company has since expanded and changed its name to WTG-Quantor GmbH. WTG-Quantor is now represented in all major wine-growing countries worldwide, incorporating over 80 countries, including Chile, South Africa and Australia.

Functions

Quantor's equipment range covers the following functions:

  • Cold settling of must and juices
  • Fermentation control, including control by CO2 monitoring
  • Malolactic fermentation control (with heating option standard on most units)
  • Micro/macro oxygenation
  • Rapid cooling of wort
  • Long term control of product storage temperature
  • Product chilling prior to carbonation
  • Cold stabilisation

The Range

The range includes Chiller Units, Heating & Chiller Units, Temperature Control Systems, & Air Conditioning Units - please see Temperature Control & Chilling.

What we offer...

We have over 10 years' experience providing and customising Kreyer temperature control solutions, from individual machines to complete computerised systems. We can offer you:

  • Advice on the appropriate equipment for you - taking budget, space and desired throughput, and labour, etc., into consideration
  • A comprehensive quotation outlining recommended solution/s and clear specifications
  • We can include Speidel stainless steel tanks (as listed in Tanks) with heating/cooling jackets, which work in conjunction with Kreyer systems
  • Supply, installation (including the construction of ringmains) and commissioning by our team of experienced, multi-skilled Vigo engineers
  • Comprehensive 12 month warranty, backed up by our team of Vigo engineers
  • Maintenance & full technical backup and support from our mobile engineers
  • Spare parts



Case Studies

The Case Studies below represent a few of the multiple Kreyer temperature control systems we have installed:

How can we help you?

If you're looking for chilling or temperature control solutions, please give us a call on 01404 892 100 and we will be happy to discuss your requirements.
